M18 ONEFPRT-X RIVET TOOL
Code: MIL4933478601
Loading...



Product Description

 M18 ONEFPRT-X RIVET TOOL

This ONE-KEY rivet tool is an optimised cordless solution which delivers fast, easy riveting while maintaining performance, durability, and size.

Features:

-This particular tool is capable of pulling up to 900 rivets with a rivet size of 4.8 mm in aluminium or 500 rivets with a size of 6.4 mm in aluminium on a fully charged M18™ 2.0 Ah battery pack.

-Ability to fasten all blind rivets including aluminium, steel, stainless steel and copper from 4.8 mm, 6.0 mm, 6.4 mm and 7.0 mm to give you a bigger range of applications to be completed.

-Features 20,000N of pulling force with a stroke length of 30mm. This gives the user the power to complete the larger diameters effortlessly.

-More work between jaw changes due to to the premium steel alloy 3-jaw design.

-Tool-free access to easily clean jaws. Design includes on-board nose piece storage and wrench for user convenience.

-Design includes transparent mandrel collector. This allows the user to see when the mandrel collector is full, avoiding any mandrel jammings and minimising down time to unblock jammings also avoiding costly repairs at the same time.
">-Integrated ONE-KEY™ technology giving the users the complete digital tool management package.
">-M18 FUEL™ rivet tool with ONE-KEY™ integrates three MILWAUKEE®-exclusive technologies - the POWERSTATE™ brushless motor, REDLITHIUM™ battery pack and REDLINK PLUS™ intelligence hardware and software - which deliver outstanding power, run time and durability on the jobsite
-Flexible battery system which works with all Milwaukee M18 Batteries.
Specifications
Voltage (V) 18
Weight (Kg) -
Dimensions (mm) 317 x 63 x 273
Article Number 4933478601
Battery pack capacity (Ah) ?
Battery type Li-ion
Supplied in HD Box
Stroke length (mm) 30
Kit Included ?
Max. pulling force [N] 20,000
Rivet diameter range [mm] 4.8 - 7.0
Weight with battery pack (EPTA) (kg) 2.5 (M18 B2)
Max. rivets popped with M18 B2 battery [mm] 900 x 4.8 / 500 x 6.4
Technical Specifications
Specifications No. of batteries supplied
